MRCOOL® Hyper Heat 2nd Gen 36K BTU 3 Ton 17.4 SEER2 Central Ducted Heat Pump Condenser, CENTRAL-36-HP-C-230B00-O
MRCOOL® Hyper Heat 2nd Gen 36K BTU 3 Ton 17.4 SEER2 Central Ducted Heat Pump Condenser, CENTRAL-36-HP-C-230B00-O
Product Description
MRCOOL® Central Hyper Heat 36K 3-Ton Ducted Heat Pump Condenser (230V)
The MRCOOL® Central Hyper Heat 36K (3-Ton) Condenser is engineered for homeowners who need maximum performance in extreme climates without sacrificing efficiency. Built with DC inverter and variable-speed technology, this 2nd Generation Hyper Heat system delivers smooth, consistent comfort through freezing winters and high-heat summers.
With a strong 17.4 SEER2 efficiency rating and 37,000 BTU of heating capacity, this condenser is designed for cold-climate performance where traditional heat pumps lose efficiency. It pairs perfectly with the MRCOOL® VersaPro® 3-Ton Central Ducted Air Handler and is also compatible with dual-fuel installations using gas or electric furnaces, giving installers and homeowners full system flexibility.
The system operates on R-454B refrigerant, a next-generation low-GWP refrigerant that meets modern environmental standards. The outdoor unit features a painted galvanized steel cabinet, quiet operation at 62.5 dBA, and complete WiFi and app-based control via the (sold separately) MRCOOL® Smart Thermostat.
Backed by an industry-leading 10-year warranty covering the compressor, parts, and labor, the MRCOOL Central Hyper Heat 36K condenser delivers long-term reliability, efficiency, and peace of mind.
COMPATIBILITY & SYSTEM PAIRINGS
✔ MRCOOL® VersaPro® 3-Ton Central Ducted Air Handler
✔ Compatible with gas or electric furnaces (dual-fuel ready)
✔ Optional electric heat kits supported
✔ MRCOOL® Smart Thermostat (sold separately)
✔ WiFi & mobile app control
TECHNICAL SPECIFICATIONS
Series: Central Ducted Hyper Heat – 2nd Gen
Model: CENTRAL-36-HP-C-230B00-O
Unit Type: Split System Heat Pump
Equipment Type: Outdoor Condenser
Cooling Capacity: 36,000 BTU
Heating Capacity: 37,000 BTU
Tonnage: 3 Ton
SEER2: 17.4
EER2: 11.7
HSPF2 (Region 4): 10.2
HSPF2 (Region 5): 8.6
Voltage: 208/230V
Phase: 1
Frequency: 60 Hz
Max Breaker: 30A
Min Circuit Ampacity: 29A
Refrigerant Type: R-454B
Refrigerant Charge: 126.99 oz
Liquid Line: 3/8”
Suction Line: 3/4”
Sound Rating: 62.5 dBA
Certifications: ENERGY STAR®, AHRI, ETL
WiFi / App Control: Yes
Warranty:
• 10-Year Compressor
• 10-Year Parts
• 10-Year Labor
DIMENSIONS & WEIGHT
Net Dimensions:
• Width: 38.58”
• Depth: 16.34”
• Height: 38.39”
Net Weight: 204.15 lbs
Shipping Dimensions:
• Width: 45.08”
• Depth: 19.68”
• Height: 42.52”
Shipping Weight: 253.23 lbs
Note: These units are designed for use with No Vac Quick Connect Line Sets, which come pre-charged with R-454B refrigerant for a quicker and easier installation. Line sets are not included but can be purchased separately. If you prefer the traditional flare nut configuration, you're in luck—stub pipes and copper nuts are included
