MRCOOL® Hyper Heat 2nd Gen 30K BTU 2.5 Ton 16.8 SEER2 Central Ducted Heat Pump Condenser, CENTRAL-30-HP-C-230B00-O
MRCOOL® Hyper Heat 2nd Gen 30K BTU 2.5 Ton 16.8 SEER2 Central Ducted Heat Pump Condenser, CENTRAL-30-HP-C-230B00-O
Product Description
MRCOOL® Central Hyper Heat 30K 2.5-Ton Ducted Heat Pump Condenser (230V)
The MRCOOL® Central Hyper Heat 30K (2.5-Ton) Condenser is engineered for homeowners who need serious heating power in winter without sacrificing cooling efficiency in the summer. Built with DC inverter and variable-speed technology, this 2nd Generation Hyper Heat system delivers smooth, consistent comfort while keeping operating costs in check.
Rated at 16.8 SEER2 and delivering up to 34,000 BTU of heating output, this condenser is designed to perform reliably in cold climates where standard heat pumps fall short. It pairs seamlessly with the MRCOOL® VersaPro® 2.5-Ton Central Ducted Air Handler and can also be integrated into dual-fuel systems with gas or electric furnaces, giving installers and homeowners maximum system flexibility.
The system uses R-454B refrigerant, a next-generation, low-GWP solution that meets modern efficiency and environmental standards. The outdoor unit features a painted galvanized steel cabinet, quiet operation at just 60.5 dBA, and full WiFi and app-based smart control through the (sold separately) MRCOOL® Smart Thermostat.
Backed by an industry-leading 10-year warranty covering the compressor, parts, and labor, the MRCOOL Central Hyper Heat 30K condenser delivers long-term confidence along with powerful, energy-efficient comfort.
COMPATIBILITY & SYSTEM PAIRINGS
✔ MRCOOL® VersaPro® 2.5-Ton Central Ducted Air Handler
✔ Compatible with gas or electric furnaces (dual-fuel ready)
✔ Optional electric heat kits supported
✔ MRCOOL® Smart Thermostat (sold separately)
✔ WiFi & mobile app control
TECHNICAL SPECIFICATIONS
Series: Central Ducted Hyper Heat – 2nd Gen
Model: CENTRAL-30-HP-C-230B00-O
Unit Type: Split System Heat Pump
Equipment Type: Outdoor Condenser
Cooling Capacity: 30,000 BTU
Heating Capacity: 34,000 BTU
Tonnage: 2.5 Ton
SEER2: 16.8
EER2: 11.7
HSPF2 (Region 4): 10
HSPF2 (Region 5): 8.3
Voltage: 208/230V
Phase: 1
Frequency: 60 Hz
Max Breaker: 30A
Min Circuit Ampacity: 29.5A
Refrigerant Type: R-454B
Refrigerant Charge: 105.82 oz
Liquid Line: 3/8”
Suction Line: 3/4”
Sound Rating: 60.5 dBA
Certifications: ENERGY STAR®, AHRI, ETL
WiFi / App Control: Yes
Warranty:
• 10-Year Compressor
• 10-Year Parts
• 10-Year Labor
DIMENSIONS & WEIGHT
Net Dimensions:
• Width: 37.24”
• Depth: 16.14”
• Height: 31.89”
Net Weight: 164.02 lbs
Shipping Dimensions:
• Width: 42.91”
• Depth: 19.68”
• Height: 34.84”
Shipping Weight: 174.6 lbs
Note: These units are designed for use with No Vac Quick Connect Line Sets, which come pre-charged with R-454B refrigerant for a quicker and easier installation. Line sets are not included but can be purchased separately. If you prefer the traditional flare nut configuration, you're in luck—stub pipes and copper nuts are included
Frequently Asked Questions (FAQ)
Is this compatible with furnaces?
Yes. This condenser can be paired with a central air handler or installed in dual-fuel systems using gas or electric furnaces.
What makes Hyper Heat different?
Hyper Heat systems maintain strong heating output in cold climates where standard heat pumps lose capacity.
What refrigerant does it use?
The system uses R-454B, a modern low-GWP refrigerant.
Why Buy From MRCOOL DIRECT?
When you order from MRCOOL Direct, you get:
- ✅ Authorized MRCOOL® dealer – Your warranty is protected
- ✅ Factory-fresh units – No refurbished or mystery sources
- ✅ Fast U.S. shipping – Most in-stock items ship in 1–3 business days
- ✅ Financing options – Make high-efficiency comfort more affordable
- ✅ Real product support – Help with sizing, line set selection, and DIY questions
- ✅ No third-party marketplace middlemen – Just genuine MRCOOL® systems from a trusted MRCOOL® dealer.
BUY DIRECT!
Feel Free to call us anytime. Family Friendly help just a dial away. We love talking HVAC
615-553-8118
Family owned & USAs #1 MRCOOL® Authentication Dealer.
